SPA Pump, Series DXD-330AS

SPA Pump, Series DXD-330AS
Request a Quote
Working conditions
  • Medium temperature: 5-50℃
  • Environmental temperature: ≤50℃
  • Humidity: 65% RH
  • Maximum working pressure: 0.4MPa
With proven product quality and performance, we are confident to offer:
  • Pool equipment wholesale for distributors
  • Everything needed from pool and Spa equipment to pool accessories for pool & Spa contractor
  • OEM service for branded suppliers and manufacturers of pool equipment and supplies
  • Manufacturing service of pool equipment and supplies for the factories with limited production capacity and product variations.
Technical data
Model Voltage Power Rotating speed(r/min) Maximum Lift(m) Maximum flow(l/min) Insulation class Protection grade Gross weight(kg)
KW HP
DXD-320AS 230V/50Hz 1.50 2.0 2850 11.0 783 F IP X5 20.0
0.30 0.5 1450 1.5 366
DXD-325AS 230V/50Hz 1.90 2.5 2850 14.0 833 F IP X5 20.0
0.35 0.5 1450 2.0 422
DXD-330AS 230V/50Hz 2.1 3.0 2850 15.5 866 F IP X5 20.0
0.40 0.6 1450 3.5 433

Packing: 420mm×215mm×255mm         Container:20': 1100pcs     40' 2200pcs
Optional function: timer & no water protection
