Request a Quote
  • LED type SMD5050
  • LED quantity 30pcs/m (9pcs/foot)
  • IP rating IP20
  • Light color RGB color

Characteristics
The addressable LED strip light kit includes a 5m colored LED strip, power adapter, controller, 3M adhesive backing and a silicone-made buckle.

  • The light strip uses a TM1829 control system, which is dedicated for LED constant current driver and to achieve color gradient, light strobing and color chasing.
  • Flexible LED strip light is covered with PU glue, it features smooth surface, high light transmittance, rapid heat dissipation. It has an IP rating of IP65 which can prevent intrusion of general solid objects. The LED power supply and LED controller are non-waterproof, so it’s only suitable for dry occasions.
  • When the rated DC voltage is 12V, the maximum power will be 7.2W, environment protection and energy saving.
  • Flexible LED strip light allows a bending angle of no less than 60°and bending diameter no less than 7cm.
  • The light strip is available in 5m, you could cut a different length for your project and request.
  • This strip is easy for installation, with 3M adhesive backing or use of a buckle for fixation.
Technical specification
LED strip light specification
LED type SMD5050
LED strip light voltage(V) DC12V
Working power 7.2W/M(Max)
Controller IC TM1829
Light color RGB
Beam angle 120°
Dimension(MM) 5000×10×0.2mm
Material Fpc
Warranty 2 years
Working temperature -40-50℃
Storage temperature -50-60℃
Inner package 5M/Roll
Parameters for power adapter
Input voltage AC100-240V
Input frequency 50/60 Hz
Output voltage DC12V (constant voltage)
Output current 2A(Max)
Output power 24W(Max)
Over-voltage protection 15V(Max)
Environment temperature 0℃-40℃、10%RH-90%RH
Storage temperature -20℃-60℃、5%RH-90%RH
Plug EU/US/AU/BS etc.
Wire length 1.5M
Parameters for the controller
Controller voltage DC12V
Control mode 20 types
Control type 24-key infrared remote controller
Output 3 Channels (3*2A)
Power 72W (Max)
Lighting arrangement RGB
Sensing distance 7M(Max)
Working temperature -20-50℃

Installation
There is a 3M adhesive on back and you just need to tear off the protective paper and paste it on. You could cut the light strip into different lengths upon request.

Package
Applications
  • Billboards, lighting projects, house decoration or other lightings.
  • Outline or road markings.
  • Ceilings, corridors windows or roadway decoration.
  • Backlit nameplate or sign.
  • Indoor bars or KTV lighting.
