1.8 Degree Size 57mm 2-Phase Hybrid Stepper Motor

1.8 Degree Size 57mm 2-Phase Hybrid Stepper Motor
Request a Quote

Nema 23 2 phase Hybrid Stepper Motor

Features
Large acceleration, small moment of inertia, high precision

Application
Medical industry: Biochemical analyzer, blood cell analyzer
Textile industry: Flat knitting machine, circular knitting machine, bobbin winder
Advertising industry: Laser machine, engraving machine, marking machine, inkjet printer
Industrial automation industry: Semiconductor testing equipment, winding machine, stripping machine
Water treatment industry: Screw pump
Bank equipment: ATM
Others: Metro fare collection system, etc.

Item Specifications
Step Angle 1.8º
Step Angle Accuracy ±5% (full step, no load)
Resistance Accuracy ±10%
Inductance Accuracy ±20%
Temperature Rise 80℃ Max. (rated current, 2 phase on)
Ambient Temperature -20℃~ 50℃
Insulation Resistance 100MΩ Min., 500V DC
Dielectric Strength 500V AC for one minute
Radial Play 0.02 Max. (450 g-load)
Axial Play 0.08 Max. (450 g-load)
Max. Radial Force 75N (20mm from the flange)
Max. Axial Force 15N
Model Rated Voltage Current per Phase Resistance per Phase Inductance per Phase Holding Torque Number of Leads Rotor Inertia Weight Detent Torque Length
Single Shaft Double Shaft V A Ω mH kg·cm
g·cm2 kg kg·cm mm
FL57ST41-1106A FL57ST41-1106B 4 1.1 3.6 3.6 2.88 6 57 0.54 0.18 41
FL57ST41-0406A FL57ST41-0406B 12 0.4 30 30 2.88 6
FL57ST41-1564A FL57ST41-1564B 2.8 1.56 1.8 3.6 4.0 4
FL57ST51-0856A FL57ST51-0856B 6 0.85 7.1 9 4.97 6 110 0.60 0.35 51
FL57ST51-0426A FL57ST51-0426B 12 0.42 29 36 4.97 6
FL57ST51-2804A FL57ST51-2804B 2.38 2.8 0.85 2.1 6.9 4
FL57ST56-1206A FL57ST56-1206B 6 1.2 5 8 6.05 6 135 0.65 0.42 56
FL57ST56-0606A FL57ST56-0606B 12 0.6 20 32 6.05 6
FL57ST56-2554A FL57ST56-2554B 2.8 2.55 1.1 3.6 8.4 4
FL57ST76-1506A FL57ST76-1506B 5.4 1.5 3.6 6 9 6 200 0.95 0.72 76
FL57ST76-0686A FL57ST76-0686B 12 0.68 17.7 30 9 6
FL57ST76-3304A FL57ST76-3304B 2.7 3.3 0.85 3 12.5 4
