Request a Quote

Applicable Materials
The CMA 1200-H single head CO2 laser cutter is designed for the cutting of non-metallic materials like paper, leather, cloth, acrylic, wool, and plastic.

Cutting System

Model Laser power (W) Laser head Working area (mm) Overall dimension (mm) Weight
(Kg)
Speed (m/min) Supply voltage Working environment
CMA1200-H 60~130 Single 1200×600 4500×1160×1170 374 0~30 AC220V±10% Temp: 5~40°C,
Humidity: 5~80%.
No condensate water, no dust or less dust.

Laser Processing Examples:

  • Leather fabrics laser cutting
  • Leather laser hollowing and cutting
  • Plush toy laser cutting
  • Leather Luggage and bags laser cutting
  • Garment laser cutting
  • Towel laser cutting
  • Fabrics laser cutting and punching processing

Product Feature
1. Two working tables can automatically switch, allowing for continuous working and material loading.
2. The CMA1200-H laser cutting system is equipped with a quick continuous curve cutting function. The maximum cutting speed can be up to 30m/min.
3. The laser intensity is automatically compatible with the movement speed of the cutting nozzle, so as to guarantee cutting precision.
4. Signal will not be distorted during long-distance transmission. Anti-interference capability is excellent.
5. This laser cutter can save 128 working files. It is able to work off-line. It is suitable for mass production and multi-batch tasks.
