INCONEL 601 (UNS N06601) High-temperature alloy

INCONEL 601 (UNS N06601) High-temperature alloy
INCONEL 601 (UNS N06601) High-temperature alloy
Request a Quote
Features
  • This alloy is resistant to high temperature oxidation, avoiding oxidation up to 1204℃.
  • Inconel 601 alloy has good high temperature strength, and retains its ductility even after long periods of exposure to heat.
  • Highly resistant to carburization
  • Good creep rupture strength
  • Excellent mechanical properties at both room temperature and high temperature
  • Metallurgical stability
Chemical Analysis
% Ni Cr C Mn Fe Si Cu P Al S
UNS N06601 Min. Balance 21 - - 10 - - - 1 -
Max. Balance 25 0. 1 1 15 0. 5 1 0. 03 1.7 0. 015
Physical Properties
Density 8.1G/CM3
Melting Range 1320-137°C
The Min. Mechanical Properties under Room Temperature
Alloy Tensile Strength Yield Strength Elongation Brinell Hardness
RM N/MM2 RPO.2 N/MM2 A5% HB
Annealing 650 300 30 -
Solution Treatment 600 240 30 ≤220
  • Applications
    • Chemical Processing
    • Radiant tubes
    • Power generation
    • Heat treating industry
