Application
The RHJ-B vacuum mixing emulsifying machine is designed to mix makeup, cream and ointment, toothpaste and other high viscosity materials. This type of machine can realize internal circulation homogenization or external circulation homogenization. The mixing capacity is up to 3000L, which is especially suitable for the the mixing of large capacity emulsions.

Technical parameter
RHJ-B100 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
100L 2.8-4 1440/2880 1.5 0-63 2750 2700 2250 13 32 -0.09
RHJ-B200 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
200L 6.5-8 1440/2880 2.2 0-63 3100 3000 2500 15 45 -0.09
RHJ-B300 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
300L 6.5-8 1440/2880 2.2 0-63 3500 3350 2650 18 49 -0.085
RHJ-B500 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
500L 6.5-8 1440/2880 4 0-63 3850 3600 2750 22 61 -0.08
RHJ-B1000 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
1000L 9-11 1440/2880 5.5 0-63 4200 3850 3300 28 88 -0.08
RHJ-B2000 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
2000L 11-14 1440/2880 5.5 0-63 4500 4050 3800 34 _ -0.08
RHJ-B3000 vacuum mixing emulsifying machine
Capacity Homogenizer motor Stir Motor Dimension Total Power Limit vacuum (Mpa)
KW r/min KW r/min Length(mm Width(mm) Height(mm) Steam heating Electric heating
3000L 15-18 1440/2880 7.5 0-63 4800 4300 4100 40
-0.08

Feature
1. The emulsifying machine adopts advanced vacuum suction technology, which has a superior effect for powder materials and effectively prevents dust explosion.
2. The mixing process of materials is performed in a vacuum condition to prevent bubbles in high speed stirring and reach the request of sanitation and asepsis.
3. Our emulsifying machine is equipped with CIP cleaning system. All parts contacted with materials is made from SUS316L and the internal surface of equipment is polished according to 300EMSH health standards.
4. Hydraulic lifting system is design with sealing device ensuring more stable and safe lifting process.
5. The bottom of emulsifying vessel adopts flat bottom discharge valve ensuring complete discharging without residue.
6. By setting temperature and heating time, our machine can realize automatic heating and freezing.
7. Out emulsifying machine adopts bidirectional stirring, the direction of inner impeller and outer impeller can be switched on a timer.
8. The vessel cover is equipped with glass sight lighting to watch the processing condition of materials in the emulsifying vessel.
9. A sprinkler ball is installed on the cover of emulsifying machine, which can clean the whole vessel completely as it is free of dead corners.
10. The complete machine is made of SUS316 or SUS304 stainless steel.
11. When emulsifying vessel is in vacuum, material can be suctioned from oil phase vessel and water phase vessel. The vessel has tube that prevent reverse flow occurring and prevent crystals from forming in the surface of vessel.

Yuxiang as a leading vacuum mixing emulsifying machine manufacturer and supplier, mainly provides emulsion mixing equipment for cosmetics manufacturing plant, household chemical manufacturing plant. Our company offer complete cream process line including mixing, agitating, dispensing, emulsifying, homogenizing, filling and sealing as well as custom solutions. For the different types of materials like lotion, cream, ointment products, our vacuum emulsifying mixer machines can be designed and configured in customer needs.
