500W Lifting Motor, PMDC Brushed Motor ZD080A2

500W Lifting Motor, PMDC Brushed Motor ZD080A2
500W Lifting Motor, PMDC Brushed Motor ZD080A2
500W Lifting Motor, PMDC Brushed Motor ZD080A2
Request a Quote
Power
Your Motion

Application: electric material handling equipment including cranes, industrial trucks, forklifts, AGVs, etc.

Technical Specifications
Rated Power (W) 500
Rated Voltage(V) 24
No-load Revolution (RPM) 4500±6%
No-load Current (A) ≤3.5
Rated Current (A) 30
Rated Torque(N•m) 1.35
Rated Revolution (RPM) 2600±6%
Working Cycle (min.) S2-10
Insulation Class F
Protection Level IP44
Insulation Resistance >20 MΩ
Length (mm) 151

Note: UNITE MOTOR can customize any brushed lifting motors according to your requirements and working conditions.
