4UM-120D Vegetable Harvester
Request a Quote
Automatic Leafy Greens Harvester
Characteristics
- Automatic profiling of header height allows for the automatic adjusting of header height according to the height of the ground, so that the cutting assembly can cut at a uniform height. It is especially suitable for harvesting multi-cropping leafy greens.
- The operation panel is added with fault self-detection function to ensure a more labor-saving and safe operating.
- Intelligent positioning function allows for real-time displaying harvested area in unit of mu.
- Harvesting Chinese little greens
- Harvesting Chinese cabbage
- Harvesting lettuce
Specifications
| Item | Unit | Index |
| Model | / | 4UM-120D |
| Mobility | / | Walk-behind |
| Mating power | / | Motor |
| Rated power | 1 | |
| Battery type | Lithium iron phosphate | |
| Battery capacity | AhV | 48V 40ah |
| Braking mode | / | Drum brake |
| Drive mode | Electrical rear-wheel dual drive | |
| Moving mode | / | Walk straight |
| Cutter type | / | Reciprocating double knife cutterbar |
| Profiling device | / | Automatic profiling |
| Dimensions (L×W×H) | mm | 2180×1500×1200 |
| Cutting width | mm | 1200 |
| Cutting height | mm | Manual 0-100 Electrical 10-60 |
| Conveying device | Crawler type conveyor belt | |
| Belt width | mm | 1200 |
| Guide wheel spacing | mm | 800 |
| Drive wheel spacing | mm | 800 |
| Minimum ground clearance | mm | 70 |
| Harvesting speed | m/s | 0.2-0.4 |
| Harvesting capacity | hm2/h | 0.02~0.08 |
| Operation display | mu | Real-time display |
