LK13-1 Rigid Coupling - Setscrew Type

LK13-1 Rigid Coupling - Setscrew Type
LK13-1 Rigid Coupling - Setscrew Type
LK13-1 Rigid Coupling - Setscrew Type
Request a Quote
Dimensions
Note: the model with S is the stainless steel type, and the model without S is aluminium alloy type
please let us know the model and the φd1φd2 of product you need.
Model φd1φd2
Max. Bore Diameter
φD L L1 M Wrench Torque
( N.M )
LK13-16 6 16 24 6 M3 1.2
LK13-20 10 20 30 7 M3 1.2
LK13-25 12 25 36 9 M4 2.5
LK13-32 16 32 41 10 M4 2.5
LK13-40 20 40 44 10.5 M5 5
SLK13-16 6 16 24 6 M3 1.2
SLK13-20 10 20 30 7 M3 1.2
SLK13-25 12 25 36 9 M4 2.5
SLK13-32 16 32 41 10 M4 2.5
SLK13-40 20 40 44 10.5 M5 5
Specifications
Model Rated Torque
( N.m )
Max.Torque
( N.m )
Max.Rotational Frequency
( rpm )
Moment of Inertia
( Kg.m2 )
Mass ( g )
LK13-16 0.3 0.6 23000 3.1X10-7 13
LK13-20 0.5 1 18000 8.5X10-7 24.5
LK13-25 1.0 2 14000 2.6X10-6 43
LK13-32 2.0 4 10000 9.1X10-6 55
LK13-40 4 8 8000 1.5X10-5 120
SLK13-16 0.45 0.9 23000 8.1X10-7 28
SLK13-20 0.75 1.5 18000 2.2X10-6 54
SLK13-25 1.5 3.0 14000 7.1X10-6 100
SLK13-32 3.0 6.0 10000 2.4X10-5 190
SLK13-40 6.0 12.0 8000 3.75X10-5 240

For more information, .
