Can Leak Tester
Request a Quote
About Us: http://can-equipment.com
ST-B7C (L) Automatic Upright Type
Our leak tester uses a vacuum/negative pressure system to test empty cans.
Advantages
1. Our leak testing equipment uses two detectors on the inlet and outlet to measure the negative pressure value.
2. The voltage is generated by the vacuum degree and drives the PLC to generate data.
3. The metal can leak tester has a set of dictators installed at the entrance gate, which ensures that testing will not occur when there is no can.
4. Our leak detector actively drags cans to avoid can collision or falling into the wagon. Failed cans automatically get ejected by high pressure air.
| Machine Type | | |
| Number of Testing Head | 40 | 20 |
| Suitable Diameter of Can | 202D-401D | 401D-603D |
| Suitable Height of Can | 48-180mm | 80-200mm |
| Production Rate | Up to 500 cans/min | Up to 150 cans/min |
| Vacuum Pressure | 450mbar | 400mbar |
| Required Power | 5KW | |
| Required Amount of Compressed Air | 100L /min AT 6 BAR | |
| Accuracy | Up to0.10mm | |
