Carbide Knives
HENGLIDA also specializes in the manufacturer of tungsten carbide machine knives and blades. These cutting knives are made of different hard alloys, including T8A, T10A, 9CrSi, Cr12MoV, W6Mo5Cr4V2, among other materials. We manufacture tungsten carbide knives and blades in straight, circular, and pointed tip shapes with an array of toothed, serrated, scalloped and other tooth configurations. These blades are ideal for cutting corrugated board, paper, plastic, lithium battery materials and more. With the use of our tungsten carbide machine knives, your slitting machine will require only rare knife replacement throughout the duration of it’s service life.
We offer bespoke machine knives and industrial blades with a thickness tolerance of ±0.001mm and a surface roughness of Ra0.1μm. We will design and produce any custom tungsten carbide knife within 25 business days according to the customer provided drawing or parameters.
Specifications | Matched Cutting Machine | Cutting Efficiency |
Φ220×Φ115×1 | Agnati | 50000-80000pcs/year |
Φ230×Φ110×1.1 | Fosber | |
Φ230×Φ135×1.1 | Fosber | |
Φ240×Φ32×1.2 | BHS | |
Φ240×Φ115×1 | Agnati | |
Φ250×Φ150×0.8 | Peters |
Specifications | Applications |
Φ100 ×Φ 65 × 0.7 Φ100 ×Φ 65 × 2 | Used for cutting anode plates and cathode plates of lithium battery. Matched makes of slitting machine: ARECONN, HAONENG, SEVENSTAR, CLG Electric, NISHIMURA |
Φ68 ×Φ 46 × 0.5 Φ60 ×Φ 40 × 5 | Suitable for cutting electrode plates of parallel-plate capacitor |
Φ100 ×Φ 65 × 1 Φ100 ×Φ 65 × 3 | Used for cutting anode plates and cathode plates of lithium battery. Matched makes of slitting machine: NISHIMURA, HONBRO |
Φ110 ×Φ 90 × 1 Φ110.2 ×Φ 90 × 1 Φ110 ×Φ 75 × 3 | Used for cutting anode plates and cathode plates of lithium battery. Matched makes of slitting machine: NISHIMURA, HONBRO, HAONENG |
Φ130 ×Φ 88 × 1 Φ130 ×Φ 70 × 3 Φ130 ×Φ 70 × 5 | Used for cutting anode plates and cathode plates of lithium battery. Matched makes of slitting machine: Toray, DALI, SHIFT HORSE |
