The press fitting is composed of a main body, a steel bushing, a plastic part and a seal ring.

The main material is brass generally made from CW617N or CU57-3. The steel bushing is made of 304 stainless steel with a wall thickness of at least 0.8m (the wall cannot be too thin, otherwise the risk of leaks increases, thus affecting performance levels.), The plastic parts can be customized with a nylon material to enhance the hardness, ensuring the steel bushing remains firmly attached. The seal rings are made of EPDM material with a high temperature resistance and a long service life.

We also provide surface treatments of electroplating, and all brass parts are machined using CNC lathes to ensure product dimensional accuracy.

Shown here are products we can provide, and we offer customization services in terms of shape, material, weight and size.

  • Male Straight Press Fittings Nickel Plated
      Model:
      VF-0430
      Specification:
      16mm x 1/2"
      18mm x 1/2"
      16mm x 3/4"
      26mm x 3/4"
      20mm x 1/2"
      20mm x 3/4"
      26mm x 1"
    1. Female Straight Press Fittings Nickel Plated
        Model:
        VF-0431A
        Specification:
        16mm x 1/2"
        18mm x 1/2"
        20mm x 1/2"
        20mm x 3/4"
        26mm x 1"
        26mm x 3/4"
    1. Straight Press Fittings Nickel Plated
        Model:
        VF-0432
        Specification:
        16mm x 16mm
        18mm x 18mm
        20mm x 16mm
        20mm x 20mm
        26mm x 20mm
        26mm × 26mm
        26mm x 16mm
    1. Male Elbow Press Fittings Nickel Plated
        Model:
        VF-0433
        Specification:
        16mm x 1/2"
        18mm x 1/2"
        16mm x 3/4"
        20mm x 3/4"
        20mm x 1/2"
        26mm x 3/4"
        26mm x 1"
    1. Female Elbow Press Fittings Nickel Plated
        Model:
        VF-0434A
        Specification:
        16mm x 1/2"
        18mm x 1/2"
        20mm x 1/2"
        20mm x 3/4"
        26mm × 3/4"
        26mm × 1"
    1. Elbow Press Fittings Nickel Plated
        Model:
        VF-0435
        Specification:
        16mm x 16mm
        18mm x 18mm
        20mm x 20mm
        26mm x 26mm
    1. Wall Seat Press Fittings Nickel Plated
        Model:
        VF-0436
        Specification:
        16mm x 1/2"
        18mm x 1/2"
        20mm x 1/2"
        20mm x 3/4"
    1. Female Tee Press Fittings Nickel Plated
        Model:
        VF-0438
        Specification:
        16mm x 1/2" x 16mm
        18mm x 1/2" x 18mm
        20mm x 1/2" x 20mm
        26mm x 3/4" x 26mm
        26mm x 1" x 26mm
    1. Tee Press Fittings Nickel Plated
        Model:
        VF-0439
        Specification:
        16mm x 16mm x 16mm
        18mm x 18mm x 18mm
        20mm x 16mm x 20mm
        20mm x 16mm x 16mm
        20mm x 20mm x 16mm
        20mm x 20mm x 20mm
        26mm x 26mm x 26mm
        26mm x 16mm x 26mm
        26mm x 20mm x 26mm
