Vibrating Fluid Bed Dryer
Vibrating fluid bed dryer is enhanced and specialized drying machine whose function is to dry the materials finally. Our vibrating fluid bed dryer also has functions of pelleting, cooling, sieving, and conveying. Nowadays, it has been widely used in sugaring, medicine, chemical fertilizer, chemical industry, plastic, dairy, salt industry, mining and metallurgy.
The operating principles
This vibrating fluid bed dryer resembles in appearance with traditional horizontal dryers. The main difference lines in that the former is supported by a spring and based on a base, and vibration motor is installed on one or both sides of the drying equipment.
Application fields
1. A vibrating fluid bed dryer is ideal for using in medical and chemical industries for drying pills, particles, boric acid, borax, and so on.
2. Used in food and building materials industry to dry MSG, granulated sugar, salt, slags and seeds.
3. A dryer is also applicable for drying mineral powder, metal powder, steel grit, bait, furfural, silica sand, toner, glutamic acid, quartz, abrasive, fertilizer, and more.
LIGHT Company is a China based manufacturer of vibrating fluid bed dryer. Given below is some salient features of our drying equipment.
1. Uniform heating, sufficient heat exchange and high intensity drying enables the dryer to save 30%-50% energy in comparison with traditional ones.
2. Driven by vibrating motor, the vibrating fluid bed dryer features steady operation, easy maintenance, low noise and long service life.
3. Materials are conveyed uniformly and this guarantees good drying and cooling effect.
4. The drying machine won't cause any damage to the material surface, so it is also suitable for fragile materials.
5. Fully enclosed structure ensures high sanitation standard.
| Capacity | 150Kg/Hr (Final Products); |
| Dimension | 5000*1100*1800; |
| Fluid Bed Size | 4500*280*150mm; |
| Power | 6.7Kw; |
| Gas Consumption | 5-6Kg/Hr; |
| Moisture Removal | 10%; |
| Application Range | Breadcrumb, Rice Power; |
We also manufacture some related products like meat production equipment, pellet snack machinery, pet food machinery and bread crumb processing machine. All of them are approved by CE. We welcome you to purchase these products.
