Introduction
Silicon oxide grinding ball is made of high purity and fine talc ceramic powder by rolling, isostatic pressing and high temperature roasting. Silicon oxide ball is a economical type grinding ball with two choice of sphere and cylinder.

Application
Silicon oxide ball is suitable for dispersion and grinding low viscosity slurry. It can be used as grinding medium for paint, fuel, paint, glass, ink, gloss oil, pesticides, pharmaceuticals and other chemical and biological industries. Additionally, it can be used as medium for filter media, catalyst carrier, polishing and cleaning.

Parameters
Chemical composition
Type Wt%
SiO2 MgO Na2O CaO Al2O3 Others
SI-70 70% 2% 14% 12% 1% 1%
SI-62 62% 27%


11%
Physical nature
Type Specific gravity(kg/dm3) Bulk weight(kg/L) Moh's hardness Vickers hardness Compressive strength (N) Color Package (kg/bag)
SI-70 2.5 1.5 ≥6 630 White 20-25
SI-62 2.7 1.6 7.5 900 650(2mm) White 25
Specifications
Type Grain dia.(Φmm) Type Grain dia.(Φmm)
D-0.4 0.4-0.6 D-8 8.0
D-0.5 0.5-0.75 D-9 9.0
D-1 1.0-1.3 D-10 10.0
D-1.25 1.25-1.55 D-12 12.0
D-1.55 1.55-1.85 D-14 14.0
D-1.7 1.70-2.0 D-15 15.0
D-2.0 2.0-2.4 D-20 20.0
D-2.4 2.4-2.8 D-30 30.0
D-2.85 2.85-3.0 D-40 40.0
D-3 3.0 D-50 50.0
D-5 5.0 D-60 60.0
D-7 7.0 D-70 70.0
Advantages
  • It has low abrasion consumption, low oil absorption and low grain diameter deviation.
  • It has high strength, high sphericity, high whiteness and high gloss.
  • It can avoid pollution by other materials.
