Multihead Packing Machine

Multihead Packing Machine
Request a Quote

Features
1. This multihead packing machine is designed for packaging, dosing and weighing regular and irregularly shaped materials, such as candy, sunflower seed, potato chip, happy fruit, peanut, jelly, freezing rice dumpling, biscuit, chocolate, nut, pet food, puffed food, small metal parts and plastic parts, etc.
2. This packing machine is equipped with precision digital measuring device, and its operating system comes with LCD display screen and can display operations in multiple languages, including English, Russian, German, Spanish and Italian, etc.
3. IP65 waterproof and dustproof design. It's easy to clean and maintain.
4. Able to self-adjust during running.
5. Operation menu available to make you study and operate it more easily. The multihead packing machine is also designed with automatic data statistic function.
6. Optional configurations of this multihead packing equipment include printing equipment, suction hopper, and more.
7. High compatibility and compact structure.
8. This vertical packing machine can greatly save on materials and labor cost.

Parameters
Model LTP-500 LTP-600 LTP-800 LTP-900
Packing speed 50bags/min Max 50 bag/min 50 bags/min 45 bag/min
Bag size (L)60-300mm (W)90-200mm (L)80-350mm (W)100-250mm (L)20-400mm (W)100-300mm (L)20-450 mm (W)140-350 mm
Bag making mode Pillow-type bag, standing bag, punch Pillow-type bag, standing-bevel bag, punch bag Pillow-type bag, standing-bevel bag, punch bag Pillow-type bag, standing-bevel bag, punch bag
Range of measuring 150-1300ml 150-2000ML 3000ML MAX 4000 ML
Max packaging film width 420mm Max 520mm Max 620mm Max 730 mm
Thickness of film 0.04-0.09mm 0.04-0.09mm 0.04-0.09mm 0.06-0.12 mm
Air consumption 0.8Mpa 0.5cmb/min 0.8Mps 0.4m3/min 0.8Mps 0.6m3/min 0.8 Mps 0.8m3/min
Main power/voltage 2.2KW/220V 50Hz 2.5KW/ 220V 50Hz 2.2KW/ 200V 50Hz 4.5 KW/ 220V 50 Hz
Dimension L1458*W920*
H1392mm
L1500*W1140*
H1540mm
L1250mm*W1600mm*
H1700mm
(L)1360×(W)1630×
(H)1900 mm
weight 480kg 680kg 800kg 900 kg

As a packing machine manufacturer and supplier in China, we can also manufacture grinding machine, drying equipment and many other types of food processing equipment. We welcome you to contact us for more information. We are confident that we can provide you the food equipment you are looking for.
