Fiber Laser Cutting System CMA1540C-G-A

Fiber Laser Cutting System CMA1540C-G-A
Fiber Laser Cutting System CMA1540C-G-A
Fiber Laser Cutting System CMA1540C-G-A
Fiber Laser Cutting System CMA1540C-G-A
Fiber Laser Cutting System CMA1540C-G-A
Request a Quote

Applicable materials
Carbon steel, stainless steel, aluminum alloy, brass, galvanized sheet, aluminized zinc plate, red copper and other metal materials.

Technical Parameter
Model CMA1540C-G-A
Laser power (W) 500-1500
Working area (mm) 1500×4000
Overall dimension (mm) 6400×2200×2000
Weight (kg) 4500
Position accuracy (mm) ±0.03/1000
Reposition accuracy (mm) ±0.02/1000
Maximum speed (m/min) 60
Maximum accelerated speed (G) 0.8
Power supply Three phase 380V/50Hz/60Hz
Working environment Temp: 0~ 45°C Humidity: ≤80% No condensate water, no dust or less dust.

Samples:

Product Feature
1.Equipped with a strengthened welded lathe bed, rack double drive system and a finish milling processed imported gantry. The non-metal laser cutting machine is annealed and processed by vibration aging technology to relieve stress and control the deformation deviation within ±0.02mm.
2.The crossbeam is made of drawn aluminum profiles and processed by finishing machining. It is lightweight, rigid and offers good dynamic performance.
3.The cutting head features leapfrog function. Parabolic motion is adopted when cutting contours and leapfrog movement is available when switching cutting contours, which greatly improves cutting efficiency.
4.The crossbeam features system-controlled automatic concentrated lubrication without manual intervention, which ensures the motion precision and service life of the transmission parts.
