JX-6C460R+1 Flexographic Printing Press for Metal Printing

JX-6C460R+1 Flexographic Printing Press for Metal Printing
JX-6C460R+1 Flexographic Printing Press for Metal Printing
Request a Quote

JIN XIANG’s metallic label, 6 color printing machine with a flexo plate is capable of printing on metal materials that are able to be rolled up, including aluminum, iron, laminated aluminum foil and stainless steel. This flexographic equipment not only prints on both sides of the substrate, but also carries out rewinding operations to improve production efficiency.

We offer this 6-color flexographic printing machine for printing on metallic labels, with the parameters below for reference only. For special requirements, we are able to alter equipment configuration, or create a new machine to meet required printing effect and capacity needs.

Technical specs
Varnish station 1 set
Gearing 1/8"
Max. Web width 460mm
Max. Print width 450mm
Max. unwind width 1600mm
Max. Rewind width 1600mm
Max. Print length 460mm
Min. Print length 190.5mm
Print speed 50m/min
Machine net weight 1500KG
Machine gross weight 2000KG
Power of main engine 15KW 380V
Motor power of ink dispenser (6pcs) 420W
UV dryer 37KW
Machine size (W×L×H) 2×11×2m
