Bare Fiber Adapter

Bare Fiber Adapter
Bare Fiber Adapter
Bare Fiber Adapter
Bare Fiber Adapter
Bare Fiber Adapter
Bare Fiber Adapter
Bare Fiber Adapter
Request a Quote

Bare fiber adapter is mainly used in insertion loss test of optical pigtails and all kinds of devices. KOC provide bare fiber adapters four main types of SC, FC, LC and ST, all the number of repeated use of more than one thousand times.

Specification
  • Insertion Loss: d0.1
  • Repeatability: <0.20 dB typical change
  • Life time: ≥1000 times
  • Ferrule ID: Ф125.5um/ф126.0um
  • Working Temperature: -20 to 75°C
  • Repeatability: -40 to 85°C
Applications
  • Fiber optic link test
  • The production workshop components test
  • Temporary test equipment, and links
  • Test equipment
  • FTTX
Features
  • Various receptacle type
  • Automatic clamping device
  • Easy to operate
  • Repeated use
FC SM Bare Fiber adapter
PN Description
120-0103-101 FC SM Bare Fiber adapter, METAL
FC SM Bare Fiber adapter,Square
PN Description
122-0103-102 FC SM Bare Fiber adapter, METAL Square
SC SM Bare Fiber adapter
PN Description
122-0903-101 SC SM Bare Fiber adapter, METAL
SC SM Bare Fiber adapter,Square
PN Description
122-0903-102 SC SM Bare Fiber adapter, METAL Square
LC SM Bare Fiber adapter,Square
PN Description
122-1803-101 LC SM Bare Fiber adapter, METAL Square
ST SM Bare Fiber adapter,Square
PN Description
122-3603-101 ST SM Bare Fiber adapter, METAL Square
