MC-DHT-A Large Surface Leather Marking Machine

Request a Quote

Website: http://lasercut-group.com/3-1-1-6-large-surface-leather-marking-machine.html

Features

Fully enclosed design is safe and provides environmental protection. Humanized operating platform is simple to operate.
The entire machine body frame is welded by steel profiles and processed by artificial aging treatment, featuring concise and aesthetically pleasing appearance and high stability.
The sliding table adopts the motion system composed of imported drive parts, guide rail and servo motor, which runs smoothly and greatly improves the splicing accuracy and stability;
Imported CO2 laser source has good light spot quality and stable output power; Imported core components deliver stable performance and long service life.
Intelligent and independent board copy system can distinguish the defect of irregular leather and segment the redundant graphics, greatly improving the efficiency and process effect.
The intelligent board copy system realizes the identification and control by the Internet of things and multiple marking machines can share one board copy machine, greatly reducing the purchase cost.
Modular design facilitates transportation and realizes the free combination of different functions and customization to meet client’s needs.

Technical parameter

Model	MC-DHT-A
Laser peak power(W)	350 × 2 /600 × 2
Working efficiency	10-15min/pcs
Working area (mm)	1400 × 2700
Overall dimension(mm)	6500 ×1900 ×3500
Weight (Kg)	1500
Supply voltage	380V, 50Hz
Working environment	Temperature: 20~35℃, Humidity: 5~80%. No condensate water, no dust or less dust.
Gross power (kW)	18/24

Applicable material
This marking machine is widely used for processing large surface leather.

Laser Processing Examples:
