Gasoline Engine Take-Up Machine

Gasoline Engine Take-Up Machine
Gasoline Engine Take-Up Machine
Request a Quote

Technical Parameters

Item Number 08192 08193 08194
Model LJ-300B LJ-500A LJ-500B
Diameter of Drum Groove (mm) Φ300 Φ500 Φ500
Engine Type Honda GX270 gasoline engine R175A diesel engine Honda GX270 gasoline engine
Power (hp) 9 6 9
Rotational Speed (rpm) 3600 2600 3600
Traction Force (kN)
/
Pulling Speed
(m/min)
Slow 25/8.5 16/10.5 16/13.6
Medium 15/13.4 10/16.6 10/21.5
Fast 6/33.5 4/40.8 4/53.6
Reverse -/9.6 -/11.8 -/15.3
Overall Dimension (mm) 870×620×650 920×700×710 900×700×710
Weight (kg) 140 190 150
