Crochet Knitting Machine, JSG889/B3

Crochet Knitting Machine, JSG889/B3
Request a Quote

Textile equipment, Textile fabric equipment

As a common textile equipment type, the crochet knitting machine is suitable for the production of elastic and non-elastic narrow fabrics such as bandages, elastic earloops, laces, ribbons, and webbings.

      Features
      • High productivity due to widened working width
      • High quality bearing, rubber roller and needle bed
      • Features a durable construction, quiet operation, high operational stability, and easy control
      • The noise level and electrical safety levels are in full compliance with international standards.
      Technical Parameters
      • Working Width: 35 inch (889mm)
      • Number of Needles per inch: available with 10, 12, 14, 15, 16, 18, 20
      • Weft Guide Bar: 3 bars
      • Max. Fabric Width: 70mm
      • Motor Power: 1.5kw
      • Speed: 1500 rpm/min
      Fabric Width / Tape Numbers
      4mm 10mm 15mm 20mm 25mm 30mm 40mm 50mm 60mm 70mm 300mm
      126 (pcs) 62 (pcs) 42 (pcs) 36 (pcs) 28 (pcs) 23 (pcs) 18 (pcs) 15 (pcs) 12 (pcs) 10 (pcs) 2 (pcs)
