EMC11 X5070 2 Flute Micro Square End Mill

EMC11 X5070 2 Flute Micro Square End Mill
EMC11 X5070 2 Flute Micro Square End Mill
EMC11 X5070 2 Flute Micro Square End Mill
Request a Quote
  • Designed to machine tool steel, alloy steel, mold steel and other materials with hardness up to HRC70
  • Special long neck design for machining deep cavity, deep slotting and deep pocketing
  • Super micro end mills are available with diameters ranging from 0.02~2.9mm
  • 2 flute miniature tools are used for high precision milling in medical, optical, electronics and aerospace industries
Application
Product Specifications
Coating AITISIN HRC HRC50/65/70
Helix Angle 30°/35° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
X5070 Carbide 2 Flute End Mill, Long Length - for RIB Processing(UNT-EMC11)
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1
Effective Length
L3
Shank Dia.
D2
Flute Length
L1
O.A.L.
L2
Flutes
EMC110402 0.4 2 4 0.6 50 2
EMC110404 0.4 4 4 0.6 50 2
EMC110406 0.4 6 4 0.6 50 2
EMC110502 0.5 2 4 0.8 50 2
EMC110504 0.5 4 4 0.8 50 2
EMC110506 0.5 6 4 0.8 50 2
EMC110602 0.6 2 4 1 50 2
EMC110604 0.6 4 4 1 50 2
EMC110606 0.6 6 4 1 50 2
EMC110608 0.6 8 4 1 50 2
EMC110802 0.8 2 4 1.2 50 2
EMC110804 0.8 4 4 1.2 50 2
EMC110806 0.8 6 4 1.2 50 2
EMC110808 0.8 8 4 1.2 50 2
EMC111006 1.0 6 4 1.5 50 2
EMC111008 1.0 8 4 1.5 50 2
EMC111010 1.0 10 4 1.5 50 2
EMC111012 1.0 12 4 1.5 50 2
EMC111014 1.0 14 4 1.5 60 2
EMC111016 1.0 16 4 1.5 60 2
EMC111018 1.0 18 4 1.5 60 2
EMC111020 1.0 20 4 1.5 60 2
EMC111206 1.2 6 4 1.8 50 2
EMC111208 1.2 8 4 1.8 50 2
EMC111210 1.2 10 4 1.8 50 2
EMC111212 1.2 12 4 1.8 50 2
EMC111214 1.2 14 4 1.8 60 2
EMC111216 1.2 16 4 1.8 60 2
EMC111218 1.2 18 4 1.8 60 2
EMC111220 1.2 20 4 1.8 60 2
EMC111506 1.5 6 4 2.5 50 2
EMC111508 1.5 8 4 2.5 50 2
EMC111510 1.5 10 4 2.5 50 2
EMC111512 1.5 12 4 2.5 50 2
EMC111514 1.5 14 4 2.5 60 2
EMC111516 1.5 16 4 2.5 60 2
EMC111518 1.5 18 4 2.5 60 2
EMC111520 1.5 20 4 2.5 60 2
EMC112006 2.0 6 4 3 50 2
EMC112008 2.0 8 4 3 50 2
EMC112010 2.0 10 4 3 50 2
EMC112012 2.0 12 4 3 50 2
EMC112014 2.0 14 4 3 60 2
EMC112016 2.0 16 4 3 60 2
EMC112018 2.0 18 4 3 60 2
EMC112020 2.0 20 4 3 60 2
EMC112025 2.0 25 4 3 60 2
EMC113008 3.0 8 6 4.5 60 2
EMC113010 3.0 10 6 4.5 60 2
EMC113012 3.0 12 6 4.5 60 2
EMC113014 3.0 14 6 4.5 60 2
EMC113016 3.0 16 6 4.5 60 2
EMC113018 3.0 18 6 4.5 60 2
EMC113020 3.0 20 6 4.5 60 2
EMC113025 3.0 25 6 4.5 60 2
EMC114012 4.0 12 6 6 60 2
EMC114014 4.0 14 6 6 60 2
EMC114016 4.0 16 6 6 60 2
EMC114018 4.0 18 6 6 60 2
EMC114020 4.0 20 6 6 60 2
EMC114025 4.0 25 6 6 60 2

• End mills with non-standard sizes or specifications not listed above can be customized according to customer needs.
