Paramagnetic Oxygen Analyzer SR-2030ExP (Flameproof Type)

Paramagnetic Oxygen Analyzer SR-2030ExP (Flameproof Type)
Request a Quote

Paramagnetic oxygen analyzer adopts a flameproof enclosure. We adhere to the principle that an explosion proof oxygen analyzer should have excellent shell strength and maximum surface temperature. The circuit is isolated from the surrounding environment, thus can prevent ignition of flammable and explosive gases around it. This paramagnetic oxygen analyzer is used to carry out continuous oxygen concentration measurement.

This gas analyzer is suitable for the detection of explosive gas and its mixture containing the IIC T6 group and below and the mixture of steam and air for hazardous areas of zone 1 or 2.

Application areas

Industrial fields of chemical fertilizer, chemical industry, metallurgy, air separation, and cement production, and continuous detection on gas concentration in fields of environmental protection and pollution source.

Main specification
Range 0-100%c
Repeatability Cv≤1%FS
Zero drift ≤±1%FS
Span drift ≤±1%FS
Response time T90< 4S
Sample gas flow rate 200ml/min
Preheating time 20min(actionable);120min(highest precision)
Signal output 4-20mA/750Ω,RS232/485
Alarm High-limit alarm, low-limit alarm (relay),constant on, 5A/220V
Temperature and humidity 0-45℃, 20-80%RH
working power supply 220VAC±10%, 50Hz±1Hz
explosion-proof degree Ex d ⅡC T6 Gb
Enclosure rating IP65
Features
  • High precision magneto mechanical oxygen sensor featuring good stability, with non-destructive testing method
  • A direct measurement of the paramagnetism of the mixed gas.
  • Maintenance free.
  • Automatic humidity and temperature compensation
  • Small gas consumption, minimum 100ml/min.
  • The response time is less than 45s.
  • High accuracy and resolution is 0.001.
  • Vibration resistance
  • Automatic zero correction, no loss of data when power-off.
  • Measuring range can be set arbitrarily.
  • It has RS232/485 interface and can be connected with DCS.
