Silo Truck

Request a Quote

About Us: http://janeoocn.com/5c-tank-truck.html

Model: SDX5250ZBG;

Features of Silo Truck
Dry mix mortar silo truck is compatible with various different mortar storage tanks. Thus long distance dry-mixed mortar transportation is permitted.
Fully hydraulic control system and manual controlled control valve are equipped for mortar-storage-tank mounting and dismounting.

Applications of Dry Mix Mortar Silo Truck
Dry-mixed mortar silo truck is mainly used for carrying mortar storage tanks, whether they are full loaded or unloaded.

Technical Parameters of Dry Mix Mortar Silo Truck

Name		Dry-mixed mortar silo truck (heavy duty truck 20m³)	Dry-mixed mortar silo truck (heavy duty truck 20m³)
Model		SDX5250ZBG	SDX5160ZBG
Curb weight (kg)		12925	7790
Total weight (kg)		25000	12000
Overall dimensions (L x W x H) (mm)		9660 x 2500 x 2960	9590X2500X2760
Model of chassis		ZZ1257M4647C	DFL5160XXYBX1
Wheel base (mm)		4600 1350	5600
Model of engine		WD615.93E	ISDe180 30
Displacement (L) / Power (kW)		9.726/213	4.5/132
Tank	Standard	SB/T 10461-2008
	Volume (m³)	≤20m³
	Diameter (mm)	2400
Hydraulic system		Open circuit	Open circuit
Pressure (MPa)		28MPa	16MPa
Fuel tank capacity (L)		240	120
Flip angle (º)		95º

Note: The above parameters are subject to change without prior notice.
