H05RN-F Multicore Rubber Insulated Power Cable
Conductor: Bare copper, tinned copper
Insulator: EPR rubber
Jacket: CPE rubber
Rated volt.: 300/500V, 450/750V
Test voltage: 2000V. 5Min
Rated temp.: -30℃~ 70℃
Application
Rubber insulated power cable is popularly used in locomotive equipment, electric motor, marine cable, mineral, underwater, welding machines etc.
Core×Size | Construction | Insulation | Jacket thickness | Cable OD | Resistance Ω/KM | ||
Thickness | OD | Nominal | Toler. | ||||
mm² | No./Dia (mm) | mm | mm | mm | mm | mm | Max. |
2×0.5 | 16/0.20 | 0.6 | 2.15 | 0.8 | 5.9 | ±0.20 | 40.1 |
3×0.5 | 16/0.20 | 0.6 | 2.15 | 0.8 | 6.2 | ±0.20 | 40.1 |
4×0.5 | 16/0.20 | 0.6 | 2.15 | 0.8 | 6.8 | ±0.25 | 40.1 |
5×0.5 | 16/0.20 | 0.6 | 2.15 | 0.8 | 7.4 | ±0.30 | 40.1 |
2×0.75 | 24/0.20 | 0.6 | 2.35 | 0.8 | 6.3 | ±0.20 | 26.7 |
3×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 7.1 | ±0.25 | 26.7 |
4×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 7.7 | ±0.30 | 26.7 |
5×0.75 | 24/0.20 | 0.6 | 2.35 | 1.0 | 8.4 | ±0.30 | 26.7 |
2×1.0 | 32/0.20 | 0.6 | 2.55 | 1.0 | 7.1 | ±0.25 | 20.0 |
3×1.0 | 32/0.20 | 0.6 | 2.55 | 1.0 | 7.5 | ±0.30 | 20.0 |
4×1.0 | 32/0.20 | 0.6 | 2.55 | 1.0 | 8.2 | ±0.30 | 20.0 |
5×1.0 | 32/0.20 | 0.6 | 2.55 | 1.0 | 8.9 | ±0.30 | 20.0 |
2×1.5 | 30/0.25 | 0.6 | 2.90 | 1.0 | 7.8 | ±0.30 | 13.7 |
3×1.5 | 30/0.25 | 0.6 | 2.90 | 1.0 | 8.3 | ±0.30 | 13.7 |
4×1.5 | 30/0.25 | 0.6 | 2.90 | 1.0 | 9.0 | ±0.30 | 13.7 |
5×1.5 | 30/0.25 | 0.6 | 2.90 | 1.1 | 10.0 | ±0.30 | 13.7 |
Mechanical Properties
Insulator physical performance
Tensile strength: ≥5N/mm2
Elongation at break of insulation: ≥250%
Jacket physical performance
Tensile strength: ≥7N/mm2
Elongation at break of insulation: ≥300%
Min.Bending radius: 7×OD
Standards: IEC60332-1, IEC60228, VDE 0293
Characteristics
Rubber cable has good performance, including low hardness, good flexibility, high tear strength, flame retardant performance, thermal stability. It can bear the temperature from -30℃ ~ 70℃. It’s also anti-UV and anti-ozone.
Other similar styles: H05RN-F, H05RR-F, H07RN-F, YZW, YZ, YC, YCW
