H01N2-D Welding Cable
Conductor：bare/tinned copper class 5 flexible
Separate tape: PE tape
Insulator: EPDM/CPE Rubber
Color: Black or Orange or based on customer demands
Rated Volt.：300/500V
Rated Temp.：-35℃～ 85℃
Mechanical properties
Insulator physical performance
Tensile strength: ≥7N/mm2
Elongation at break of insulation: ≥300%
Min. Bending radius: 6×OD
Standards: IEC60332-1, IEC60228, VDE 0293
Application
Our welding cables are suitable for application as entertainment or stage lighting cables for movie theaters, lighting systems, sound systems, and communications equipment. Additional uses for welding cables include battery cables for cars, inverter cables, and as an affordable alternative to pendant/reeling cable for hoists and cranes. For example, many solar power installations use welding cable to effectively connect solar panels, battery banks, and converters.
| Nominal section area (mm2) | Max. diameter of wire (mm) | Coated layer thickness (mm) | Average outer diameter (mm) | Max. resistance at 20℃ (Ω/km) | ||
| Min. | Max. | Tin coated wire | Copper wire | |||
| 10 | 0.21 | 2.0 | 7.8 | 10.0 | 1.190 | 1.160 |
| 16 | 0.21 | 2.0 | 9.2 | 11.5 | 1.190 | 1.160 |
| 25 | 0.21 | 2.0 | 10.0 | 13.0 | 0.780 | 0.758 |
| 35 | 0.21 | 2.0 | 11.5 | 14.5 | 0.552 | 0.536 |
| 50 | 0.21 | 2.2 | 13.5 | 17.0 | 0.390 | 0.379 |
| 70 | 0.21 | 2.4 | 15.5 | 19.5 | 0.276 | 0.268 |
| 95 | 0.21 | 2.6 | 17.5 | 21.5 | 0.204 | 0.198 |
| 120 | 0.21 | 2.8 | 19.5 | 24.0 | 0.164 | 0.161 |
| 150 | 0.21 | 3.0 | 22.5 | 26 | 0.132 | 0.129 |
| 185 | 0.21 | 3.2 | 23.0 | 29.0 | 0.108 | 0.106 |
Characteristics
Resistant to cuts, tears and abrasion in addition to moisture.
Welding Wire offers good color retention along with great flexibility.
