720B BSP Bolt (British Standard Pipe)
Request a Quote
Application: for use with hydraulic braided hoses
Materials:- Stainless steel BSP bolt (British Standard Pipe)
- Carbon steel BSP bolt (British Standard Pipe)
| Part No. | Thread | Dimensions | ||||
| E | A | B | C | S1 | ||
| 720B-04 | M1/4''×19 | 28.5 | 6 | 6 | 19 | |
| 720B-06 | M3/8''×19 | 38.5 | 9 | 7 | 22 | |
| 720B-08 | M1/2''×14 | 44 | 13 | 8.5 | 27 | |
| 720B-10 | M5/8''×14 | 48.5 | 15 | 10 | 30 | |
| 720B-12 | M3/4''×14 | 56 | 18 | 10 | 32 | |
| 720B-16 | M1''×11 | 68.5 | 22 | 13 | 41 | |
