Applications
The gantry pellet pelletizer is suitable for cutting materials after the extrusion and thermoplastic drawing of thermoplastic elastomers, high filling materials and glass fiber composite materials. The pelletizer is capable of cutting material into different sizes.

Parameter
Type BR125/GR125 BR240/GR240
Cutting Rotor (mm) φ180*125 φ180*240
Strand Speed (m/min) 83 83
AC Motor 3phase/380V/50HZ 3phase/380V/50HZ
Drive Motor (KW) 5.5/7.5 7.5/11
Driver Control Frequency Converter Frequency Converter
Max. number of strands (pcs) 30 60
Pellet Size (mm) φ3*3 φ3*3
Material of cutter High-speed Steel/ Hard Alloy
Overall dimension(L*W*H) (mm) 1106*1195*1600 1106*1315*1600
Gross Weight (kg) 468 495
Features
  • Low noise and excellent stability.
  • It is safe and easy to clean
  • The particle length can be customized according to the user's requirement, and the particle standard is φ3*3.
  • The particles are not at risk of contamination because the pelletizing process is carried out in a separate space.
  • Due to its internal lock design, the machine can only be turned on under specific, secure environmental conditions, thus ensuring operator safety.

Index
plastic pelletizing, granulation equipment, pellet machine
