Central Axle Trailer
Description:
We developed a central axle trailer in two different types for customers to choose from: all aluminum, or composite plate. Both feature a light weight, high strength and excellent loading capabilities, thus improving transportation efficiency and providing support for drop and pull transportation. Customers from both Europe and America have utilized our central axle trailer, to excellent results.
| Parameter | 20000 x 2500 x 3900 | Total weight | 36000kg |
| Central Axle Trailer | |||
| Dimension | 11250 x 2550 x 3990 | Inner Dimension | 8860 x 2506 x 2688 |
| Volume | 59m³ | Weight | 8180kg |
| Rated load | 9820kg | wheel base | 6500mm |
| Central Axle Trailer | |||
| Dimension | 8000 x 2550 x 2800 | Inner Dimension | 7958 x 2506 x 2678 |
| Volume | 53m³ | curb weight | 3820kg |
| rated load | 14180kg | Suspend | air suspension |
| wheel base | 5495+1310 | ||
| Parameter | 20000 x 2500 x 3900 | Total weight | 36000kg |
| Central Axle Trailer | |||
| Dimension | 11250 x 2550 x 3990 | Inner Dimension | 8860 x 2506 x 2688 |
| Volume | 59m³ | Weight | 8180kg |
| Rated load | 9820kg | wheel base | 6500mm |
| Central Axle Trailer | |||
| Dimension | 8000 x 2550 x 2800 | Inner Dimension | 7933 x 2476 x 2608 |
| Volume | 51m³ | curb weight | 4740kg |
| rated load | 13260kg | Suspend | plate spring |
| wheel base | 5495+1310 | ||
Sanxing has been manufacturing heavy duty vehicles and special vehicles since 1994. Besides the central axle trailer, we offer a wide range of aluminium alloy tank trailer, stainless steel tank trailer, carbon steel stainless steel tank trailer and so on. From the raw material selection to manufacturing process, we have rich experience and offer high quality central axle trailers and other special transport vehicles with custom solutions.
