WN200TA(50-500)S-G Motorized Linear Stage

WN200TA(50-500)S-G Motorized Linear Stage
WN200TA(50-500)S-G Motorized Linear Stage
WN200TA(50-500)S-G Motorized Linear Stage
WN200TA(50-500)S-G Motorized Linear Stage
Request a Quote

WN200TA(50-500)S-G precision motorized linear stage is suitable for providing linear motion of electronic control in automatic motion control for scientific research, full-automatic measuring and testing equipment, industrial automation and others. It has a table size of 150×150mm, load capacity 50kg, and a wide travel range from 50mm to 500mm.

Parameter table of precision motorized linear stage
Model WN200TA50S-G WN200TA100S-G WN200TA200S-G WN200TA300S-G WN200TA400S-G WN200TA500S-G
Travel 50mm 100mm 200mm 300mm 400mm 500mm
Table Size 150×150mm 150×150mm 150×150mm 150×150mm 150×150mm 150×150mm
Screw Type High precision ball screw (lead 5mm)
Load Capacity 50 kg
Weight 14kg 17kg 20kg 23kg 26kg 29kg
Resolution 10µ (Non-microstepping driver) 0.5µ (20 microstepping driver)
Maximum Speed 30mm/sec
Positioning repeatability <1µ
Straightness 10µ 15µ
Driving parallelism 15µ 20µ 25µ







Features of precision motorized linear stage
  • Featuring with high load capacity and high rigidity with linear slide guide, the precision motorized linear stage is suit for industrial processing, laboratory or other places requiring high load and long-term continuous operation.
  • High weight and higher stability with stainless steel platform. Suit for the case of large changes in ambient temperature and humidity.
  • High performance with 5 phase stepper motor. Greatly improved the positional accuracy with linear scale to realize closed-loop control.
  • High precision ball screw drive, great repeatability and positional accuracy, small axial clearance and long service life.
  • Equipped with dustproof cover.
