2ZG-6DM Riding Type Rice Transplanter

2ZG-6DM Riding Type Rice Transplanter
Request a Quote
Characteristics
  • The front wheels of 2ZG-6DK riding rice transplanter can absorb shock independently, helping you work safely and comfortably.
  • With large horsepower and large fuel tank, the rice transplanter can work at a high speed for a long time, which increases work efficiency.
  • Thetranplanter has low fuel consumption and is cost saving.
  • The transplanting depth can be adjusted using this riding type rice transplanter.
  • This agricultural machine adopts independent planting units, which makes the number of transplanting rows adjustable.
Specifications
Model 2ZG-6DM
Dimensions (L×W×H) (mm) 3485×2200×2240
Minimum ground clearance (mm) 388
Total weight (kg) 720
Engine Manufacturer Yanmar
Model 3TNM68-AMW
Type Vertical water-cooling diesel engine with three cylinders and four strokes
Rated power (kW) 12.3
Maximum revolving speed (r/min) 3600
Fuel Diesel
Tank capacity (L) 20
Traveling portion Drive mode Four-wheel drive
Wheel Front (mm) Solid tyre φ650
Rear (mm) Rubber lug wheel φ950
Shifting system Hydraulic stepless speed-change
Shifting gear Forward: two speeds Reverse: one speed
Transplanting portion Number of rows 6
Transplanting mode Rotary type
Row spacing (mm) 300
Transplating distance (seedling to seedling) (mm) 220, 180, 160, 140, 120
Number of hills (each 3.3m2) 50, 60, 70, 80, 90
Transplanting depth (mm) 10-40 (6 stages)
Balancing device Machinery
Seedling taking quantity Horizontal (time) 18,20 (14),26
Vertical (mm) 8-17
Working speed (m/s) 1.55
Fuel consumption (L/mu) 0.45
Productivity (mu/h) 6
