WN10VA120 Motorized Lab Jack
Request a Quote
Our WN10VA120 motorized lab jack adopts scissor mechanism and double guide rails positioning mechanism, ensuring stable motion, high load and long service life. Driven by precision screw lead, the motorized lab jack can lift freely with minimal backlash.
| Model | WN10VA120 | |
| Structure | Travel | 120 mm |
| Table size | 240mm×165mm | |
| Driving gear | Ultra-fine lead screw | |
| Guide rail | Slide guide | |
| Stepper motor (1.8°) | STP-57BXG152 | |
| Material | Aluminum alloy | |
| Surface | Blackened by anodic oxidation | |
| Center load capacity | 20kg | |
| Weight | 6.1kg | |
| Accuracy | Minimum adjustment | 5μ(Non-MS driver) 0.25μ(20 MS driver) |
| Maximum speed | 5mm/sec | |
| Repeatability | 10μ | |
| Backlash | 4μ | |
| Step-out | 3μ | |
