1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System

1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
1550 × 1000mm Double Head CO2 Laser Cutter, CMA1610-T-A Laser Cutting System
Request a Quote

Applicable Materials
Wooden products, paper, leather, cloth, polymethyl methacrylate, epoxy resin, acrylic, woolens, plastics, rubber, bamboo ware, garment materials, leather products, mobile phone accessories, adhesive decals, rhinestone, plastic nozzle, screen protector, jade and other non-metallic materials.

Cutting System

Model Version Laser power
(W)
Laser head Working area
(mm)
Overall dimension (mm) Weight
(Kg)
Repeated positioning accuracy
(mm)
Speed
(m/min)
Supply voltage Working environment
CMA1610-T-A HoLi 60~130 Double 1550 × 1000 2240 × 1780 × 1290 605 ±0.1 0~30 AC 220~240V,
50/60Hz
Temperature: 5~40℃; Humidity: 5~80%. No condensation, no dust or less dust.

Laser Processing Examples:

  • Children's wear plush fabrics laser cutting
  • Garment laser hollowing
  • Leather handbag laser hollowing
  • Non-woven fabric dust bag storage bag laser cutting
  • Plush slippers fabric laser cutting

Product Feature
1. The laser cutter body is integrated with various auxiliary equipment’s power supply. The machine’s back is designed with a large cabinet for storing auxiliary equipment.
2. Independently researched and developed SmartCarve software can realize high-speed and stable running for precision laser cutting.
3. No. CMA1610-T-A laser cutting system supports 10/100m Internet and USB 2.0 transmission.
4. This laser cutter supports the display of dynamic process path and coordinate points, with real-time display of processing progress.
5. This laser cutter supports engraving recovery after power off, as well as a working time preview within extreme precision.
6. Optional large format camera and projector positioning function
