Egg Roll
  1. Egg Roll / Wafer Stick

The regular wafer stick machine, or wafer roll machine shown here is a general solution that we provide for common wafer stick production. This industrial food machinery utilizes liquefied petroleum gas or natural gas as its fuel, and can produce center-filled or hollow wafer sticks.

Hollow Wafer Stick(one/two colors)

Pressed Wafer Stick

Wafer Stick With Cream Filling

Chocolate Enrobing Wafer Stick

Pillow-shaped Wafer Stick 2

Technical Parameters of Regular Wafer Stick Machine
ItemsSpecifications
Main Machine Dimension2480 × 1800 × 2300 mm
Main Machine Weight4300kg
Batter/Cream Feeder Size (L× W× H)800 × 800 × 800mm
Cooling Conveyor Dimension (L× W× H)4000 × 350 × 950 mm
Capacity50kg /h (100pcs/min)
Power supply3-380V, AC
Gas typeLPG / natural gas
Baking wheel materialSpecial heat-resistant cast iron alloy
Baking wheel diameterφ 2000mm
Mode of bottom heatingDirect fire heating
Mode of top heatingInfrared burner from Japan
Safety protection methodCut the burner and alarm automatically by ignition control module
Burner cutting methodPneumatic
Forming machine bearing brandJapan NSK
Forming machine motor brandTaiwan Yusin Gearmotor
Frequency converter brandJapan Panasonic
Igniter solenoid valveTaiwan
Ignition controllerTaiwan Kingpin
Electrical controller componentFrance Schneider
Main forming machine cover304 stainless steel
Conveyor cover304 stainless steel
Technical Parameters of 10kg Batter Mixer
ItemsSpecifications
Mixing capacity10 kg /time
Power supply3-380V, AC
Motor power2.2kw
Material of mixing bowl304 stainless steel
Material of mixing tool304 stainless steel
Electrical controller componentFrance Schneider
Cover material304 stainless steel
