Tube Filler and Sealer GRRB-3060A (thick liquid / cream / paste packaging)
Request a Quote
Application
The tube filler and sealer is mainly used for filling high viscosity liquid, like silicone sealant, modified silane adhesive, polyurethane sealant, etc.
Description
This tube filler and sealer is mainly used for filling composite film. Be careful not to break the film when filling. The aluminum film hot sealing forming mechanism can protect the film from damage. This tube filler is a packaging equipment integrating composite aluminum film hot sealing, metering and clipping.
Technical parameters
| Filling speed | 20-25 cartridges/min |
| Filling accuracy | ±2g/590ml |
| Filling range | 280ml-600ml (customization is offered for larger capacity) |
| Overall power | 9.5KW |
| Gas pressure | 0.7MPa |
| Gas consumption | 100L/min |
| Working pressure of hydraulic system | 7-9Mpa |
| Hydraulic cooling mode | Air cooling |
| Machine size (L x W x H) | 2000x1100x2000mm |
| Net weight | 1.3T |
Note: our company matches the voltage and frequency of equipment for customers in different regions.
Structure
- Automatic filling mechanism 01: Actuator
02: Metering mechanism - Aluminum film hot sealing device 01: Hot sealing mould
- Automatic clipping 01: Products cutting, clipping structure
- Aluminum film conveying 01: Gear motor
02: Film feeding conveyor belt
03: Film conveying clip - Products discharge mechanism 01: Products rotating mechanism
- Automatic code-printing
- Optional manual or automatic operation for filling volume adjustment
- Fault alarming and displaying
