KY125(D) Medium Pressure Crawler Drilling Rig
Our KY125(D) medium pressure crawler drilling rig is a piece of mature open-pit mining equipment. It has powerful propulsion and rotating mechanisms and a centralized operation control system. The detailed information is described below.
Feature
1. Powerful propulsion and rotating mechanisms
The rotating mechanism is driven by a high-power hydraulic motor, which can provide powerful torque reserve. Thus the drill bit is less likely to be jammed. The super power hydraulic motor driven propulsion mechanism can generate as high as 20kN rising power to adjust the pressure regulating valve on the propulsion pilot valve, so that a proper propelling force for our medium pressure crawler drilling rig can be achieved.
2. Centralized operation control system
The advanced hydraulic system and pneumatic system are under centralized control, making the operation quite simple. The hydraulic operating valve can make the drill boom rise and swing, and drive the drill rig pitch, tilt, move forward and backward, and so on. The drilling performance of our medium pressure crawler drilling rig is quite stable. By controlling the pneumatic valve, you can make the oil pump start-up, and drive the vehicle advance, lift, rotate, strike, and so on. Thus the drilling vehicle could achieve a high drilling efficiency.
Specifications
| Medium pressure crawler drilling rig | ||
| Model | KY125(D) | |
| Rock hardness | F=6-20 | |
| Hole diameter | Ф80-115mm | |
| Economic drilling depth | 25m | |
| Pressure | 0.7-1.4Mpa | |
| Air consumption | ≥15m³/min | |
| Rotating speed | 0-65r/min | |
| Rotation torque | 2000N.m | |
| Lifting capacity | 17000N | |
| Propulsion type | Hydro-Cylinder-Chain | |
| Propulsion length | 3000mm | |
| Drill rod specification | Φ64×3000mm/Φ76×3000mm | |
| Gradeability | 30° | |
| Ground clearance | 290mm | |
| Walking speed | 2km/h | |
| Drill arm rising angle | Down 25° Up 50° total 75° | |
| Drill arm swing angle | Left 45° Right 45° total 90° | |
| Carriage swing angle | Left 45° Right 100° total 145° | |
| Carriage pitch angle | Down 50° Up 135° total 185° | |
| Carriage compensation | 900mm | |
| Engine | YC2108 (33KW) | 22KW (380V/220V) |
| Overall dimension (L*W*H) | 4400×2200×2050 (mm) | |
| Total weight | 3300kg | |
| Note | Pneumatic-Hydraulic driving mechanism | |
| Drill bit diameter | 90mm | 105mm | 115mm |
| Drill rod (Diameter×L) | Φ 64×3000mm | Φ 64×3000mm | Φ 76×3000mm |
| Drill hammer | CW930 | HD45S | HD45A |
