2 in1 ESD Safe Hot Air Soldering Rework Station, Item WEP-898BD Manufacturer

2 in1 ESD Safe Hot Air Soldering Rework Station, Item WEP-898BD

Request a Quote

About Us: http://yihua-soldering.com/1-3-wep-898bd-hot-air-rework-station.html

Description
The WEP-898BD hot air rework station is an optimal welding solution for surface mounted devices, integrated chips with multiple pins, resistor-capacitors, binding posts, and printed circuit boards. The soldering iron adopts a high power heating core which also satisfies the requirements for large solder joints, difficult solder joints, heavy-duty binding posts and so on.

Technical Parameters

Rated Voltage	AC 220V±10% 50Hz
Power	700W±10％（max）
Working Environment	0～40℃ Relative Humidity＜80％
Storage Environment	－20～80℃ Relative Humidity＜80％
Machine Size	150X100X130mm
Weight	2.75kg
Hot air gun
Work Voltage	AC 220V±10% 50Hz
Output Power	650W
Temperature Range	100℃～480℃
Airflow Type	Brushless fan
Air Flow	120L/min
Temperature Stability	±5℃（Static）
Display Type	RED/GREEN LED digital display
Temperature correction type	PID controller
PID Temperature correction cycle	Express 200ms
Heating Elements	Ceramic skeleton heater
Soldering iron
Work Voltage	AC 26V±10% 50Hz
Output Power	75W
Temperature Range	200℃～480℃
Temperature Stability	±5℃（Static）
Display	RED/GREEN LED digital display
Temperature correction type	PID controller
PID Temperature correction cycle	Express 200ms
Heating Elements	Regular heater（899D） High power heater(899D )
Tip ground impedance	＜2Ω
Tip of ground voltage	＜2mV

Standard Configuration
Machine: 1 set
Air Gun Handle: 1pc
Nozzle: 4pcs (5cm, 8cm, 10cm, 13cm)
Iron Handle (including a heater and tips): 1pc
Iron Holder: 1pc
