AWM 3125 Fiberglass Braid Silicone Rubber Insulation Wire

AWM 3125 Fiberglass Braid Silicone Rubber Insulation Wire
Request a Quote

Conductor: Bare copper, tinned copper
Insulator: Silicone rubber
Jacket: Fiber glass braiding with resin coating
Rated temp: 200℃
Rated volt: 600V
Test Voltage: 2000V. 1min
Flame test: FT 2

Technical Parameters
AWG No. Size Conductor Insulation Braiding Wire OD Resist.
Ω/KM
Max.
Sturcture OD Thickness OD Nominal Tolerance
mm² No./mm mm mm mm mm mm mm
8 8.367 70/0.40 4.40 1.60 1.44 7.60 0.20 8.00 0.30 2.30
-0.15
7 10.55 84/0.40 4.60 1.60 1.44 7.80 0.20 8.20 0.30 1.79
-0.15
6 13.30 105/0.40 5.30 1.60 1.44 8.50 0.20 8.90 0.30 1.42
-0.15
5 16.77 133/0.40 6.00 1.60 1.44 9.20 0.20 9.60 0.40 1.12
-0.20
4 21.15 168/0.40 6.80 1.60 1.44 10.00 0.20 10.40 0.40 0.89
-0.20
3 26.67 210/0.40 7.60 1.60 1.44 10.80 0.25 11.30 0.40 0.707
-0.20
2 33.62 266/0.40 8.50 1.60 1.44 11.70 0.25 12.20 0.40 0.56
-0.20

Mechanical Properties
Tensile strength: ≥3.45N/mm²
Elongation at break of insulation: ≥100%
Min. bending radius: 6×OD
Standard: UL758, UL62, UL1581

Characteristics
The use of silicone rubber, a high grade corona resistant insulation material, gives the AWM 3125 fiberglass braid silicone rubber insulation wire excellent dielectric strength.
The braided synthetic yarn covering, which is applied directly over the insulation, gives the cable, because of its short braiding pitch and high compactness, an excellent mechanical protection by maintaining good flexibility.
The varnishing of the braiding results in good antifriction properties, high abrasion resistance and excellent chemical resistance against transformer oil, light fuel oil and most types of cleaning agents.
In the event of fire, no corrosive and toxic gases will be given off.
Hence, damage caused by fire can be kept to minimum.

Application
AWM 3125 fiberglass braid silicone rubber insulation wire is applicable for high temperature environment such as electron, electrical household appliance, lamps and lanterns, combustion equipment, wire harness etc.
