Twisted LSZH insulated non-sheathed fire resistant cable

Construction：
  • Conductor - Plain annealed class 2 stranded or class 5 flexible copper
  • Fire resistant layer - Mica Tape
  • Insulation - Low smoke halogen-free (LSZH)

Application:

Non-sheathed twisted cables are widely used in fire extinguishing systems, sprinklers, control panels, and exit lights in high-rise buildings, hotels, hospitals, sub-ways, and public facilities.

Cross section:
  • Class 2 copper conductor: 2C1.0~2C2.5mm2
  • Class 5 copper conductor: 2C1.0~2C1.5mm2
Temperature characteristics:
  • Conductor operating temperature: -15℃~90℃
  • Min. installation temperature: 0℃
Electrical characteristics:
  • Rated voltage: 0.6/1 (1.2) kV
  • High voltage test: 3.5kV / 5min
Color:
  • Red, black or according to customer requirements
Standard:
  • Cable design: IEC 60502-1
  • Conductor: IEC 60228
  • Fire resistant: BS6387 CWX
