Bottle Blowing Machine
Timey’s full-automatic bottle blowing machines are equipped with automatic feeding, automatic bottle picking manipulator, which can both reduce labor cost and improve production efficiency. Timey supplies customers with high quality bottle blowing machines and related mold products. Our bottle blowing machine is constructed with a servo drive system & Siemens PLC control system, significantly increasing the precision & safety of the machine and minimizing noise. The equipment is extremely energy efficient and fast as well. It is suitable for making bottles, and can be broadly used for the production of plastic bottles for packing carbonated beverages, mineral water, cosmetics, cooking oils, and even medicines.
Parameter
| Model | ....... | |||
| Usable material | PP PET PS PC AS PETG Etc. | PET PS PC AS PETG Etc. | PP PET PS PC AS PETG Etc. | ...... |
| Clamping force | 400kN | 500kN | 600kN | ...... |
| Stretching stroke | 400mm | 400mm | 380mm | ...... |
| Bottom stroke | 15mm | 25mm | 15mm | ...... |
| Cavity quantity | 2 | 1 | 4 | ...... |
| Capacity | 400-1800 P/H | 400-1000P/H | 1200-2800 P/H | ...... |
| Max. heating power | 60kw | 72kw | 160kw | ...... |
| Heating power | 20kw(Normal production) | 22kw(Normal production) | 38kw(Normal production) | ...... |
| Motor power | 0.18kw | 0.18kw | 0.18kw | ...... |
| Operation pressure | 8kg/cm2 | 8kg/cm2 | 8kg/cm2 | ...... |
| Blowing air | 1 M3 7.5kw/H | 40kg/cm2 | 40kg/cm2 | ...... |
| Weight | 1600kg | 2400kg | 3500kg | ...... |
| Dimension | 2835*1500*1940 | 3510*2050*2200 | 6380*1720*2200 | ...... |
| Max. bottle volume | 1200mL | 5000mL | 1200mL | ...... |
| Neck diameter rang | 90mm E | 120mm E | 90mm E | ...... |
| Max. container Dia. | 90mm BD | 180mm BD | 90mm BD | ...... |
| Max. container height | 270mm HB | 350mm HB | 270mm HB | ...... |
| Remarks: 1. The product listed is portion of our product. More models request, please asks for the Machinery Brochure. 2. Listed machine is for reference purpose. Machine can be produced according to clients' practical requirement. | ||||
Features
1. Mitsubishi PLC control system provides the equipment with rapid response functionality and optimal accuracy and reliability. It greatly improves the quality of the finished product.
2. The Lucifer high-pressure blow valve is produced by Parker, which can withstand pressures up to 40kg, making the product more accurate and reliable. It also extends the working life of the machine.
3. The machine can be equipped with a loading bottle manipulator and a downloading bottle manipulator. Without these components, the machine could not enable full automation.
4. The 500KN PET bottle blowing machine features a compact structure thanks to its highly efficient components.
We offer plastic machines for manufacturing plastic containers. Our bottle blowing machine is suitable for making PET bottles, PS bottles, polycarbonate bottles, AS bottles, PETG bottles, etc. We have all the production resources to make plastic blowing machines with custom made service, offering quality machines for making carbonated drink bottles, water bottles, cosmetic bottles, cooking oil containers, pharmacy bottles.
