TJ350 Copper Bus Bar & Profile Line
Request a Quote
Continuous Extrusion Machine for Copper Busbar and Profile
TJ350 range of continuous rotary extrusion machine offers an ideal solution to make copper busbars, and other types of copper products by exchanging the extrusion die. The extruded copper products are widely utilized in electric motors, power distribution cabinets, transformers, etc.
Aibang provides complete line of continuous extrusion machines for making copper bar, wire, strip and profiles. Shown below are details of the copper continuous extrusion line. The continuous extrusion line mainly includes the payoff unit, straightening machine, continuous extrusion machine, take-up unit and electrical control system.
Diagram of production line
Technical Specifications
| Model | TJ350 |
| Nominal Diameter of Extrusion Wheel（mm） | Φ350 |
| Power of Main Motor（kW） | 200 |
| Feed Stock Diameter（mm） | Φ16 |
| Copper Bar Max. Width（mm） | 100 |
| Copper Bar Max. Diameter（mm） | Φ50 |
| Sectional Area Range（mm²） | 15-1000 |
| Average Output （kg/h） | 950 |
Features
- Due to continuous extrusion technique, the TJ350 copper busbar continuous rotary extrusion line can complete copper busbar extrusion at one time, without the need for edge trimming, acid pickling, etc. Thus, both production process and production period are shortened.
- The continuous extrusion equipment won't cause production wastes such as the scrap edge of copper busbar, or the residuals in the extrusion barrel. This ensures high raw material utilization rate, and our first pass yield exceeds 95%.
- Adopting friction force for feedstock heating, our continuous rotary extrusion line for copper busbars eliminates heating and annealing steps. This makes sure the production process is simplified and environmental friendly as well due to lower energy consumption and lower carbon emission.
- Continuous rotary extrusion machines support producing products with unlimited length. This, coupled with the automatic take-up unit, makes our copper busbar forming machine highly efficient.
- When the desired busbar width is less than 100mm, our continuous rotary extrusion line offers average productivity up to 800kg/h.
