Slitting Machine for Nonwovens

Slitting Machine for Nonwovens
Slitting Machine for Nonwovens
Slitting Machine for Nonwovens
Slitting Machine for Nonwovens
Slitting Machine for Nonwovens
Request a Quote

Model: PPD-NS1600
Master roll: diameter 1500mm (max.), width1600mm
Finished roll: diameter 600mm (max.), width 1600mm (max.)
Nonwoven fabric: 25-350g/㎡
Slitting width: 50mm-1600mm
Slitting accuracy: ±1mm
Cutting edge flatness: ±1mm
Unwinding paper core diameter: 76mm
Rewinding paper core diameter: 76mm
Cutting speed: 60-200 m/min
Power supply: 380V 50HZ, 3.5-7.5kW
Machine weight: 1500kg
Machine dimensions: Length 3200mm × Width 2660-4600mm × Height 2300mm

Applications
This nonwoven roll slitting machine is mainly used for cutting and rewinding heavy nonwoven rolls into narrower rolls.

Features
  • Pneumatic mechanism is adopted, providing high slitting speed, stable running, easy operation and smooth cut edge;
  • Pneumatic circular knifes, stable performance and high efficiency;
  • Unwinding tension is controlled using electromagnetic powder brake and manual tension control;
  • Unwinding unit uses air expanding shaft;
  • Automatic length measuring;
