Single Girder Overhead Crane Manufacturer

Single Girder Overhead Crane

Request a Quote

About Us: http://zgtostacrane.com/2-1-single-girder-overhead-crane.html

Single girder overhead crane is widely used for lifting goods in factories, warehouses, and material plants. It has a reasonable structure and high overall steel strength. The overhead crane is usually used in conjunction with CD and MD electric hoists. This kind of crane equipment is not allowed to be used in flammable, explosive and corrosive environments.

Specification

Capacity	20-500t
Span	10.5-31.5m
Lifting height	≤18 m
Speed	Crane traveling speed: 3/30 4/40m/min Cross traveling speed: 2/20m/min Lifting speed: As per hoist (0.8/5 0.66/4 1.0/6.3 1.3/8 1.6/10)
Working temperature	-20- 60ºC
Control method	Pendant control, remote control cabinet control
Working class	A3-A7
Power source	AC-3P 240-440V 50/60HZ
Cantilever	N/A

Features

Due to simplified installation steps, the installation can be fast.
The materials for bridges and runway beams are reduced, thereby reducing costs
It is the most cost-effective choice for light and medium cranes
Light weight design reduces the load on the building structure or foundation. Normally, the overhead crane can be supported by the existing roof structure without using additional support columns
Easy to install and maintain
Long service life
It is suitable for facilities with low ceiling, which reduces the requirements for the use of space

Application

The overhead crane is an ideal choice for workshops, warehouses, material yards, and manufacturing facilities, which is usually used in steel plants, plastic plants, railways, buildings and other places.
