WN03EM50 Motorized Mirror Mounts
Request a Quote
- The motorized mirror mount is equipped with stepper motor and RS232 interface. Use the WNSC series motion controller developed by the company to realize automatic control.
- The mirror mount has good stability with high strength spring reset device installed at many places.
- Using superfine threaded screw to do adjustment, with backlash eliminating structure design, the optical mirror mount has a high resolution.
- The mirror mount has a compact structure and exquisite appearance. Fully enclosed circuit design helps avoid loosening.
- The high precision optics mount makes the lens easy to mount and disassemble. It not only has a high repeatability, but also protects the lens well.
- Different diameters of one way mirrors, lens and mirrors can be mounted. The clamping force is adjustable.
- The mirror mounts have limit function and zero position function.
| Model | WN03EM50 |
| Tilt angle about two axes | ±5° |
| Function | θx,θy two-dimensional pitching adjustment |
| Optics diameter | 50mm |
| Drive method | M6x0.25 two-axis fine threaded screw drive |
| Drive motor | Stepper motor |
| Material | Aluminum alloy |
| Surface treatment | Black anodizing |
