WN02EM100 Motorized Mirror Mounts

WN02EM100 Motorized Mirror Mounts
WN02EM100 Motorized Mirror Mounts
Request a Quote

The motorized mirror mount can be used in laser processing, optical experiments and automatic measurement and testing and other places that require precise adjustment of lens. The mirror mount can be installed with different optics of different diameters. It can be used for reflecting light, splitting light and mixing colors.

Specification
Model WN02EM100
Tilt angle about two axes ±5°
Function θx,θy two-dimensional pitching adjustment
Optics diameter 100mm
Drive method M8x0.5 two-axis fine threaded screw drive
Material Aluminum alloy
Surface treatment Black anodizing
Features
  • The motorized mirror mount is equipped with stepper motor and RS232 interface. Use the WNSC series motion controller developed by the company to realize automatic control.
  • The mirror mount has good stability with high strength spring reset device installed at many places
  • Using superfine threaded screw to adjust, with no backlash structure design, the optical mirror mount has a high resolution.
  • The mirror mount has a compact structure and exquisite appearance. Adopt fully enclosed circuit design to avoid loosening due to impact.
  • The high precision optics mount makes the lens easy to mount and disassemble. It not only has a high repeatability, but also protects the lens well.
  • The mirror mounts have limit funcion and zero position function.
