TBTXBJ-500KN / 1000KN Concrete Creep Testing Rig

TBTXBJ-500KN / 1000KN Concrete Creep Testing Rig
Request a Quote

Concrete creep testing machine is designed to determine concrete cylinder and cuboid parts under a constant pressure for a set period. It is also suitable for concrete creep deformation test under single-direction pressure at constant temperature in a humid-free environment.

Technical Parameters
Capacity 500kN/1000kN
Measurement range 0-500kN/0-1000kN
Relative reading error ±1%
Spring height 300mm
Spring compression stroke 52mm (or customized)
Max. distance between upper platen and lower platen (Compression space) 1500mm (or customized)
Power supply 220V, 50Hz
Overall dimension (without packing) 750×750×2800mm
Net weight About 800kg

Note: all platens are produced by CNC machine with surface treatment. All platens and columns are made of No. 45 steel.
