PCD/PCBN Internal Grooving Tool
Features of PCD/PCBN Internal Grooving Tool
1. The service life of PCD/PCBN internal grooving tool is 10 to 15 times that of the average hard alloy grooving tool and coating grooving tool.
2. With small vibration of the blade, the PCD/PCBN internal grooving tool can avoid the easy breaking of the set screw and the trouble of repeatedly adjusting the blades.
3. The processing precision of our PCD/PCBN internal grooving tool can reach 3 micrometers.
4. We can manufacture PCD/PCBN internal grooving tool of various specifications according to the need of our customers.
Application
The PCD internal grooving tool is used to groove and cut various materials including copper, aluminum, copper alloy, aluminum alloy, tungsten carbide and nonmetal work pieces. For example, it can be used to process aluminum alloy piston.
The PCBN internal grooving tool is used to groove and cut hardened steel, hard cast iron, grey cast iron and iron series metal work pieces.
| Dimension (mm) | |||||||||
| P | Er° | H1 | H | W/D | L | d | L1 | f | R |
| 0.5 | 60 | 10 | 20 | 20 | 120 | 12 | 25 | 9 | 0.4 |
| 0.75 | 60 | 10 | 20 | 20 | 120 | 15 | 25 | 10.5 | 0.5 |
| 1 | 60 | 10 | 20 | 20 | 140 | 18 | 30 | 12 | 0.6 |
| 1.25 | 60 | 10 | 20 | 20 | 140 | 18 | 30 | 13 | 0.6 |
Material
The tool bit of the internal grooving tools uses PCBN or PCD blanks manufactured by world famous companies including Element Six (DeBeers, E6), DI (GE), ILJIN, SMITH, SUMITOMO and TOMEI. The body part uses high quality tungsten carbide.
Worldia is an experienced PCD/PCBN internal grooving tool manufacturer based in China. We offer a variety of products, including PCD cutting tool, diamond die blank, glass cutting tool, glass cutting machine, and much more.
