Automatic Carton Strapping Machine
Request a Quote
Introduction
The automatic carton strapping machine straps end products, and is the last step for packaging cases and making them suitable for transportation. The use of a strapping machine improves end product appearances, and features a top speed of 26 straps/minute. This machine also reduces waste and costs.
| Strap width | 8, 9, 10, 11.2, 12.7, 15.5, 18, 19mm |
| Reel | Tape roll inside diameter 200~280mm, width 190-230mm |
| Strapping speed | 26 straps per minute |
| Package size | min.W260×H30mm Max. W850×H600mm |
| Sealing method | Hot melting |
| Strapping tightness | 5~80kgs |
| Power supply | 3Phase,220V-240V/380V-480V,50/60HZ |
| Table height | 500~650mm (low table) |
| Option | strapping head, strap width, power supply, conveyor belt sensor |
| Dimensions | W1879×L700×H1566mm(low table) |
| Net weight | 315kg |
