EMB04 4 Flute Solid Carbide Flat End Mill, Long Length

EMB04 4 Flute Solid Carbide Flat End Mill, Long Length
EMB04 4 Flute Solid Carbide Flat End Mill, Long Length
EMB04 4 Flute Solid Carbide Flat End Mill, Long Length
Request a Quote
About Us: http://metalworking-tool.com/3-4-emb04-hrc65-solid-carbide-flate-4-fluteslong-length.html
Product Specifications
Coating AITiN HRC HRC50/65
Helix Angle 45° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
HRC65 Solid Carbide Flat End Mill, 4 Flutes, Long Length (UNT-EMB04)
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMB04010075 1.0 4 5 75 4
EMB04015075 1.5 4 6 75 4
EMB04020075 2.0 4 8 75 4
EMB04025075 2.5 4 8 75 4
EMB04030075 3.0 4 10 75 4
EMB04040075 4.0 4 12 100 4
EMB04040100 4.0 4 12 75 4
EMB040100756 1.0 6 5 75 4
EMB040150756 1.5 6 6 75 4
EMB040200756 2.0 6 8 75 4
EMB040250756 2.5 6 8 75 4
EMB040300756 3.0 6 10 75 4
EMB040400756 4.0 6 12 75 4
EMB04050075 5.0 6 16 100 4
EMB04060075 6.0 6 25 75 4
EMB04060100 6.0 6 30 100 4
EMB04080100 8.0 8 35 100 4
EMB04100100 10.0 10 40 100 4
EMB04120100 12.0 12 45 100 4
EMB04060150 6.0 6 35 150 4
EMB04080150 8.0 8 40 150 4
EMB04100150 10.0 10 50 150 4
EMB04120150 12.0 12 50 150 4
EMB04160150 16.0 16 70 150 4
EMB04200150 20.0 20 70 150 4

• End mills with non-standard sizes or specifications not listed above can be customized according to customer needs.
