Carbide-Tipped Round-Shank Reamers, CNC Machine Reamers, UNT-EMH09

Carbide-Tipped Round-Shank Reamers, CNC Machine Reamers, UNT-EMH09
Carbide-Tipped Round-Shank Reamers, CNC Machine Reamers, UNT-EMH09
Carbide-Tipped Round-Shank Reamers, CNC Machine Reamers, UNT-EMH09
Request a Quote
About Us: http://metalworking-tool.com/9-9-emh09-carbide-tipped-round-shank-reamers.html
  • Reamers are made of carbide-tipped tool steel for excellent abrasion and heat resistance when cutting hard and abrasive materials
  • Work on aluminum, brass, bronze, fiberglass, hardened steel, iron, nickel, plastic, stainless steel, titanium, tool steel, etc.
Application
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMH09010 1.0 6 34 4
EMH09011 1.1 7 36 4
EMH09012 1.2 7 38 4
EMH09013 1.3 7 38 4
EMH09014 1.4 8 40 4
EMH09015 1.5 8 40 4
EMH09016 1.6 9 43 4
EMH09017 1.7 9 43 4
EMH09018 1.8 10 46 4
EMH09019 1.9 10 46 4
EMH09020 2.0 11 49 4
EMH09021 2.1 11 49 4
EMH09022 2.2 12 53 4
EMH09023 2.3 12 53 4
EMH09024 2.4 14 57 4
EMH09025 2.5 14 57 4
EMH09026 2.6 14 57 4
EMH09027 2.7 15 61 4
EMH09028 2.8 15 61 4
EMH09029 2.9 15 61 4
EMH09030 3.0 15 61 4
EMH09031 3.1 16 65 4
EMH09032 3.2 16 65 4
EMH09033 3.3 16 65 4
EMH09034 3.4 18 70 4
EMH09035 3.5 18 70 4
EMH09036 3.6 18 70 4
EMH09037 3.7 18 70 4
EMH09038 3.8 19 75 4
EMH09039 3.9 19 75 4
EMH09040 4.0 19 75 4
EMH09041 4.1 19 75 4
EMH09042 4.2 19 75 4
EMH09043 4.3 21 80 4
EMH09044 4.4 21 80 4
EMH09045 4.5 21 80 4
EMH09046 4.6 21 80 6
EMH09047 4.7 21 80 6
EMH09048 4.8 23 86 6
EMH09049 4.9 23 86 6
EMH09050 5.0 23 86 6
EMH09051 5.1 23 86 6
EMH09052 5.2 23 86 6
EMH09053 5.3 23 86 6
EMH09054 5.4 26 93 6
EMH09055 5.5 26 93 6
EMH09056 5.6 26 93 6
EMH09057 5.7 26 93 6
EMH09058 5.8 26 93 6
EMH09059 5.9 26 93 6
EMH09060 6.0 26 93 6
EMH09061 6.1 28 101 6
EMH09062 6.2 28 101 6
EMH09063 6.3 28 101 6
EMH09064 6.4 28 101 6
EMH09065 6.5 28 101 6
EMH09066 6.6 28 101 6
EMH09067 6.7 31 101 6
UNT EDP # Click to Order Mill Dia.
D1 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMH09068 6.8 31 109 6
EMH09069 6.9 31 109 6
EMH09070 7.0 31 109 6
EMH09071 7.1 31 109 6
EMH09072 7.2 31 109 6
EMH09073 7.3 31 109 6
EMH09074 7.4 31 109 6
EMH09075 7.5 31 109 6
EMH09076 7.6 33 117 6
EMH09077 7.7 33 117 6
EMH09078 7.8 33 117 6
EMH09079 7.9 33 117 6
EMH09080 8.0 33 117 6
EMH09081 8.1 33 117 6
EMH09082 8.2 33 117 6
EMH09083 8.3 33 117 6
EMH09084 8.4 33 117 6
EMH09085 8.5 33 117 6
EMH09086 8.6 36 125 6
EMH09087 8.7 36 125 6
EMH09088 8.8 36 125 6
EMH09089 8.9 36 125 6
EMH09090 9.0 36 125 6
EMH09091 9.1 36 125 6
EMH09092 9.2 36 125 6
EMH09093 9.3 36 125 6
EMH09094 9.4 36 125 6
EMH09095 9.5 36 125 6
EMH09096 9.6 38 133 6
EMH09097 9.7 38 133 6
EMH09098 9.8 38 133 6
EMH09099 9.9 38 133 6
EMH09100 10.0 38 133 6
EMH09101 10.1 38 133 6
EMH09102 10.2 38 133 6
EMH09103 10.3 38 133 6
EMH09104 10.4 38 133 6
EMH09105 10.5 38 133 6
EMH09106 10.6 38 133 6
EMH09107 10.7 41 142 6
EMH09108 10.8 41 142 6
EMH09109 10.9 41 142 6
EMH09110 11.0 41 142 6
EMH09111 11.1 41 142 6
EMH09112 11.2 41 142 6
EMH09113 11.3 41 142 6
EMH09114 11.4 41 142 6
EMH09115 11.5 41 142 6
EMH09116 11.6 41 142 6
EMH09117 11.7 41 142 6
EMH09118 11.8 41 142 6
EMH09119 11.9 44 151 6
EMH09120 12.0 44 151 6
EMH09130 13.0 44 151 6
EMH09140 14.0 47 162 6
EMH09150 15.0 50 162 6
EMH09160 16.0 52 170 6
EMH09200 20.0 60 195 6

• Carbide drills with non-standard sizes or specifications not listed above can be customized according to customer needs.
